约翰迪尔零件查询93 - BACKHOE BOOM CYLINDER [E21]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 1005 次

Pos.	Part No	Qty	Parts name	Comments
1.	U10688	[2]	Bushing
2.	AU14050	[1]	Hydraulic Cylinder Barrel
3.	U10750	[1]	Lock Nut
4.	U17225	[1]	Wear Ring
5A.	U14794	[1]	Piston	(SUB AU14249 AND U17225)
5B.	U17348	[1]	Piston	(A)
6.	T37379	[1]	Packing	(SUB FOR U12974, THIS APPLICATION) (SUB FOR R72828)
7.	U10289	[1]	O-Ring
8A.	U14797	[1]		(SUB AU14249 AND U17225)
8B.	U17346	[1]	Piston	(A)
9.	W11229	[1]	Ring
10.	R76790	[1]	Packing	(SUB FOR T35851)
11.	U41895	[1]	Drawer Slide	(ALSO ORDER U41822) (SUB FOR AU41438 AND U16412)
12.	U10746	[1]	O-Ring
13.	U10748	[1]	Back-Up Ring
14.	U12363	[1]	Snap Ring
15.	U11022	[1]	Seal
16.	U12368	[1]	Nut
17.	U14111	[2]	Bushing
18.	AU13649	[1]	Rod
19.	19H2676	[1]	Cap Screw	HS, SAE 8, 3/8" X 1"
19.	12H304	[1]	Lock Washer	3/8"
20.	........	[1]	Tube	( AU14047 NO LONGER AVAILABLE) RETURN
21.	AU11753	[1]	Union Fitting
22.	R26906	[1]	O-Ring
23.	U41822	[1]	Wear Ring
24.	RE10640	[1]	Hydraulic Cylinder Kit	(SUB FOR AU14263, AU13632, AU41407, AT35931 AND AR89427, THIS APPLICATION) (SUB FOR AR96520 AND AR105352)
...	AU14048	[1]	Hydraulic Cylinder	(LESS AU14047 AND AU11753)
...	AU14249	[1]	Piston-Liner Kit	PISTON
