约翰迪尔零件查询93 - BACKHOE CROWD CYLINDER [E22]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 895 次

Pos.	Part No	Qty	Parts name	Comments
1.	JD7788	[1]	Lubrication Fitting	45°, 1/4"
2.	U10745	[2]	Bushing
3.	AU12282	[1]	Hydraulic Cylinder Barrel	(WITH BUSHINGS) (6.35 MM (.250") WALL THICKNESS) (SUB AU41199, U41821, U41578 AND U41579)
3.	AU41199	[1]	Hydraulic Cylinder Barrel	(WITH BUSHINGS) 8.6 MM (.340") WALL THICKNESS)
4.	19H3239	[1]	Cap Screw	3/8" X 1-1/4"
4.	12H302	[1]	Lock Washer	1/4"
4.	24H1305	[1]	Washer	13/32" X 13/16" X 0.065"
5.	AU12285	[1]	Tube	RETURN
6.	AU11753	[1]	Union Fitting
7.	R26906	[1]	O-Ring
8.	L2235CU	[1]	Lock Nut
9.	U17337	[1]	Wear Ring
10A.	U12958	[1]	Piston	(SUB AU14244 AND U17337)
10B.	U17334	[1]	Piston	(A)
11.	T37381	[1]	Packing	(SUB FOR U12968, THIS APPLICATION) (SUB FOR R72830)
12.	R29463	[1]	O-Ring
13A.	U12957	[1]	Ring	(SUB AU14244 AND U17337)
13B.	U17347	[1]	Piston	(A)
14.	N10193	[1]	Snap Ring
15.	R76801	[1]	Packing	(SUB FOR T54815, THIS APPLICATION) (SUB FOR T35850)
16.	U41579	[1]	Hydr. Cylinder Rod Guide	(ALSO ORDER U41578) (SUB FOR AU41441, AU41443 AND U14032)
17.	L2301CU	[1]	O-Ring
18.	L2309CU	[1]	Back-Up Ring
19.	L2300CU	[1]	Snap Ring	(USE WITH 6.35 MM (.0250")
19.	U41821	[1]	Snap Ring	(USE WITH .340" WALL THICKNESS BARREL)
20.	L2029CU	[1]	Seal
21.	U12103	[1]	Nut
22.	U11121	[2]	Bushing
23.	JD7769	[1]	Lubrication Fitting	STRAIGHT, 1/4"
24.	AU12287	[1]	Rod	(WITH BUSHINGS)
25.	U41578	[1]	Wear Ring
26.	AR105387	[1]	Hydraulic Cylinder Kit	REPAIR CYLINDER (DOES NOT INCLUDE R26906 O-RING) (SUB FOR AU14257, AU12533, AU41408, AT35938, AT36834, AT52710 AND AR96530)
...	AU12292	[1]	Hydraulic Cylinder Barrel	(SUB AU41202)
...	AU41202	[1]	Hydraulic Cylinder	(INCLUDES AU11753 AND AU12285)
...	AU14244	[1]	Piston-Liner Kit
