约翰迪尔零件查询93 - BACKHOE STABILIZER CYLINDER FOR 93, 93 SERIES A, AND 94 BACKHOES [E24]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 595 次

Pos.	Part No	Qty	Parts name	Comments
1.	U11013	[2]	Bushing
2.	........	[1]	Hydraulic Cylinder Barrel	( AU13359 NO LONGER AVAILABLE)
3.	U13572	[1]	Lock Nut
4.	U17217	[1]	Wear Ring
5A.	U15554	[1]	Piston	(SUB AU14250 AND U17217)
5B.	U17349	[1]	Piston	(A)
6.	T38193	[1]	Packing	(SUB FOR U12967, THIS APPLICATION) (SUB FOR R72827)
7.	A3606R	[1]	O-Ring
8A.	U15555	[1]	Ring	(SUB AU14250 AND U17217)
8B.	U17345	[1]	Piston	(A)
9.	U14128	[1]	Snap Ring
10.	R76802	[1]	Seal	(SUB FOR T36998)
11.	U41897	[1]	Hydr. Cylinder Rod Guide	(ALSO ORDER U41823) (SUB FOR AU41437, AU41439 AND U12971)
12.	U10776	[1]	O-Ring
13.	R78993	[1]	Back-Up Ring	(SUB FOR U10777, THIS APPLICATION)
14.	U10775	[1]	Snap Ring
15.	U11019	[1]	Seal
16.	U10769	[1]	Nut
17.	AU13356	[1]	Rod
18.	U15925	[2]	Bushing
19.	U41823	[1]	Wear Ring
20.	RE18754	[1]	Hydraulic Cylinder Kit	(SUB FOR AU13631, AU14262, AU41405, AT36836, AT52703, AR96518 AND AR105407)
...	........	[2]	Hydraulic Cylinder	( AU13354 NO LONGER AVAILABLE)
...	AU14250	[1]	Piston-Liner Kit
