约翰迪尔零件查询93 - BACKHOE STABILIZER CYLINDER FOR 95 AND 95 SERIES A BACKHOES [E25]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 440 次

Pos.	Part No	Qty	Parts name	Comments
1.	U11013	[2]	Bushing
2.	AU13454	[1]	Hydraulic Cylinder Barrel
3.	P45231	[1]	Lock Nut
4.	T40416	[1]	Wear Ring	(SUB FOR U17303)
5A.	U12961	[1]	Piston	(SUB AU14246 AND T40416)
5B.	U17299	[1]	Piston	(A)
6.	T38194	[1]	Packing	(SUB FOR U12966, THIS APPLICATION) (SUB FOR R72826)
7.	R495R	[1]	O-Ring
8A.	U12959	[1]	Ring	(SUB AU14246 AND T40416)
8B.	U17300	[1]	Piston	(A)
9.	U14128	[1]	Snap Ring
10.	R76802	[1]	Seal	(SUB FOR T36998)
11.	U41823	[1]	Wear Ring
12.	U41958	[1]	Guide	(ALSO ORDER U41823) (SUB FOR U16408 AND AU41431)
13.	U12331	[1]	O-Ring
14.	R78823	[1]	Back-Up Ring	(SUB FOR R35684, THIS APPLICATION)
15.	U10136	[1]	Snap Ring
16.	U16406	[1]	Seal
17.	U10139	[1]	Nut
18.	U15925	[2]	Bushing
19.	AU13617	[1]	Rod
20.	RE18751	[1]	Hydraulic Cylinder Kit	(SUB FOR AU13652, AU14261, AU41647, AT35929, AT36829, AR96511 AND AR105405)
...	........	[2]	Hydraulic Cylinder	( AU13455 NO LONGER AVAILABLE)
...	AU14246	[1]	Piston-Liner Kit
