Pos.	Part No	Qty	Parts name	Comments
1.	AU12450	[2]	Hose Clamp
2.	R26375	[4]	O-Ring	(SUB FOR U10778)
3.	AU11569	[4]	Adapter
3.	AH17169	[2]	Adapter	(USED ON STABILIZER CYLINDER HEAD END ON JD544 AND JD644)
4.	U10516	[6]	Hose Clamp
4.	U13055	[8]	Clamp	(USED ON JD544 AND JD644)
5.	19H2633	[2]	Cap Screw	3/8" X 1-1/2"
5.	19H2633	[4]	Cap Screw	3/8" X 1-1/2"
5.	12H304	[2]	Lock Washer	3/8"
5.	12H304	[4]	Lock Washer	3/8", (USED ON JD544 AND JD644)
6.	R26906	[8]	O-Ring
7.	AW10635	[5]	Elbow Fitting	90°
8.	AT50017	[2]	Hydraulic Hose - Fabricate	CONTROL VALVE TO CYLINDER HEAD END 1359 MM (1/4" X 53-1/2") (SUB FOR AU11574 AND AU41203)
9.	AU41216	[2]	Hydraulic Hose	CONTROL VALVE TO CYLINDER ROD END 1829 MM (1/4" X 72") (SUB FOR AU13614)
10.	19H3552	[2]	Cap Screw	5/16" X 1-1/2"
11.	AW10637	[2]	Elbow Fitting	45°
12.	AW10633	[1]	Adapter
12.	AU11753	[1]	Union Fitting	90° (USED ON JD544 AND JD644)
13.	AP23054	[1]	Elbow Fitting	90°
14.	AH12285	[1]	Hydraulic Hose	CONTROL VALVE TO SWING CYLINDER 508 MM (3/8" X 20")
15.	AU40481	[1]	Hydraulic Hose	CONTROL VALVE TO SWING CYLINDER 559 MM (3/8" X 22") (SUB FOR AW11014, THIS APPLICATION)
16.	R26448	[2]	O-Ring
16.	R26375	[2]	O-Ring	(SUB FOR U10778) (USED ON JD544 AND JD644)
17.	AU11669	[2]	Elbow Fitting	90°
17.	AU11569	[2]	Adapter	(USED ON JD544 AND JD644)
18.	AP23054	[2]	Elbow Fitting	90°
