约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS - STABILIZER AND SWING CIRCUIT 94 BACKHOE ( -002381) [F10]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
866 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AU12450
|
[2] |
Hose Clamp
|
|
| 2. |
R26375
|
[4] |
O-Ring
|
|
| 3. |
AU11569
|
[2] |
Adapter
|
|
| 4. |
U10516
|
[6] |
Hose Clamp
|
|
| 5. |
19H2633
|
[2] |
Cap Screw
|
|
| 5. |
12H304
|
[2] |
Lock Washer
|
|
| 6. |
AU41216
|
[2] |
Hydraulic Hose
|
|
| 7. |
AU11581
|
[2] |
Elbow Fitting
|
|
| 8. |
AT50017
|
[2] |
Hydraulic Hose - Fabricate
|
|
| 9. |
19H2633
|
[2] |
Cap Screw
|
|
| 9. |
12H304
|
[2] |
Lock Washer
|
|
| 9. |
14H812
|
[2] |
Nut
|
|
| 10. |
R26906
|
[6] |
O-Ring
|
|
| 11. |
AW10635
|
[4] |
Elbow Fitting
|
|
| 12. |
AW10637
|
[2] |
Elbow Fitting
|
|
| 13. |
TY3000
|
[1] |
Hydraulic Hose
|
|
| 14. |
AU40481
|
[1] |
Hydraulic Hose
|
|
| 15. |
R26448
|
[2] |
O-Ring
|
|
| 16. |
AH17169
|
[2] |
Adapter
|
|
