约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS - STABILIZER CIRCUIT FOR 95 BACKHOE ( -002450) [F12]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
693 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AU13630
|
[2] |
Clamp
|
|
| 2. |
R26375
|
[2] |
O-Ring
|
|
| 3. |
AU11569
|
[2] |
Adapter
|
|
| 4. |
R26375
|
[2] |
O-Ring
|
|
| 5. |
AN31756
|
[2] |
Elbow Fitting
|
|
| 6. |
19H1849
|
[2] |
Cap Screw
|
|
| 7. |
U10516
|
[4] |
Hose Clamp
|
|
| 8. |
19H1849
|
[2] |
Cap Screw
|
|
| 8. |
12H326
|
[2] |
Lock Washer
|
|
| 8. |
14H785
|
[2] |
Nut
|
|
| 9. |
AU11576
|
[4] |
Hydraulic Hose - Fabricate
|
|
| 9. |
AU41217
|
[4] |
Hydraulic Hose
|
|
| 10. |
........
|
[1] |
Tube
|
|
| 11. |
........
|
[1] |
Tube
|
|
| 12. |
R26906
|
[4] |
O-Ring
|
|
| 13. |
AW10633
|
[4] |
Adapter
|
|
| 14. |
........
|
[1] |
Tube
|
|
| 15. |
........
|
[1] |
Tube
|
|
