约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS - BOOM, CROWD, AND BUCKET CIRCUITS 93 ( -005700) AND 95 ( -002450) EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 803 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU13294	[1]	Hydraulic Hose - Fabricate	MANIFOLD BLOCK TO R.H. CROWD CYLINDER TUBE, 1 270 MM (1/2" X 50") DOUBLE WIRE BRAID
2.	AU10807	[2]	Hydraulic Hose - Fabricate	MANIFOLD BLOCK TO BUCKET CYLINDER TUBES, 1 066.8 (1/2" X 42") DOUBLE WIRE BRAID
3.	AT34934	[2]	Hydraulic Hose - Fabricate	MANIFOLD BLOCK TO BOOM CYLINDER TUBES 2 133.6 MM (1/2" X 84") DOUBLE WIRE BRAID, (SUB FOR AU10806)
4.	TY3010	[1]	Hydraulic Hose	MANIFOLD BLOCK TO L.H. CROWD CYLINDER TUBES 1 168.4 MM (1/2" X 46") DOUBLE WIRE BRAID, (SUB FOR AU13295)
5.	19H3239	[2]	Cap Screw	3/8" X 1-1/4"
5.	12H304	[2]	Lock Washer	3/8"
5.	14H812	[2]	Nut	3/8"
6.	U10736	[1]	Clamp	TUBE, R.H.
7.	AU11678	[1]	Tube	CROWD CYLINDER, R.H.
8.	14H873	[4]	Nut	1-1/4"
9.	U16163	[4]	Elbow Fitting
10.	AU10862	[1]	Hydraulic Hose - Fabricate	TUBES TO CROWD CYLINDER, 571.5 MM (1/2" X 22-1/2") DOUBLE WIRE BRAID
11.	AU12424	[1]	Oil Line	BUCKET CYLINDER, R.H.
12.	AU13294	[2]	Hydraulic Hose - Fabricate	TUBES TO BUCKET CYLINDER, 1 270 MM (1/2" X 50") DOUBLE WIRE BRAID
13.	AU12425	[1]	Tube	BUCKET CYLINDER, L.H.
14.	AU11679	[1]	Tube	CROWD CYLINDER, L.H.
15.	AU11752	[6]	Fitting	90°
16.	R26906	[6]	O-Ring
17.	U10737	[1]	Clamp	TUBE, L.H.
18.	........	[1]	Handle	( U16454 NO LONGER AVAILABLE) FRONT
19.	........	[1]	Strap	CENTER ( U16452 USE IF AVAILABLE)
20.	U16453	[1]	Handle	REAR
21.	19H1849	[2]	Cap Screw	5/16" X 1-1/4"
21.	12H303	[2]	Lock Washer	5/16"
21.	14H785	[2]	Nut	5/16"
