约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS FOR 2010 WHEEL TRACTOR WITH 700 LOADER [F18]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 668 次

Pos.	Part No	Qty	Parts name	Comments
1.	JD179	[2]	Union Fitting	3/4" X 45° (95 ONLY)
2.	AU11787	[2]	Hydraulic Hose	609 MM (3/4" X 24")
3.	JD149	[2]	Adapter	STRAIGHT, 3/4"
4.	JD182	[1]	Hydraulic Hose	RETURN, 914.4 MM (3/4" X 36")
5.	AU11775	[1]	Hydraulic Hose - Fabricate	PRESSURE, 1 270 MM (3/4" X 50")
6.	AP23222	[2]	Elbow Fitting	3/4" X 90°
7.	U30411	[2]	Elbow Fitting	STREET, 3/4"
8.	19H1921	[1]	Cap Screw	5/16" X 3-1/4"
8.	12H303	[1]	Lock Washer	5/16"
8.	14H785	[1]	Nut	5/16"
9.	24M7207	[5]	Washer	8.400 X 24 X 2 MM
10.	........	[1]	Bracket	( U13131 NO LONGER AVAILABLE)
11.	U13635	[1]	Clamp
12.	19H2676	[1]	Cap Screw	HS, SAE 8, 3/8" X 1"
12.	12H304	[1]	Lock Washer	3/8"
12.	14H812	[1]	Nut	3/8"
13.	JD179	[2]	Union Fitting	3/4" X 45°
14.	AU10802	[2]	Hydraulic Hose	2 184.4 MM (3/4" X 86")
15.	A16711	[8]	Half Clamp	(SUB FOR 30010)
16.	19H2633	[4]	Cap Screw	3/8" X 1-1/2"
16.	12H304	[4]	Lock Washer	3/8"
16.	14H812	[4]	Nut	3/8"
17.	19H2633	[1]	Cap Screw	3/8" X 1-1/2"
17.	12H304	[1]	Lock Washer	3/8"
18.	........	[1]	Clamp	(U13061 USE IF AVAILABLE)
