约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS FOR JD500 WHEEL TRACTOR WITH 720 LOADER [F19]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS FOR JD500 WHEEL TRACTOR WITH 720 LOADER [F19]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 380 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU13396	[1]	Tube
2.	AU13623	[1]	Tube	RETURN BACKHOE VALVE (FOR 93 AND 95 BACKHOES)
2.	........	[1]	Tube	( AU41039 NO LONGER AVAILABLE) RETURN CONTROL VALVE (FOR 93 SERIES A AND 95 SERIES A)
3.	15H561	[1]	Pipe Plug	HEX, COUNTERSUNK 1/2"
4.	JD179	[2]	Union Fitting	3/4" X 45° (95 BACKHOE ONLY)
5.	AU42576	[2]	Hydraulic Hose - Fabricate	609 MM (3/4" X 24") (93 AND 93 SERIES A BACKHOE) (SUB FOR AU13637)
5.	AU13636	[2]	Hydraulic Hose - Fabricate	1 016 MM (3/4" X 40") (95 AND 95 SERIES A BACKHOES)
6.	JD149	[2]	Adapter	STRAIGHT, 3/4"
7.	U13667	[2]	Clamp
8.	19H2732	[2]	Cap Screw	3/8" X 2-3/4"
8.	12H304	[2]	Lock Washer	3/8"
8.	14H812	[2]	Nut	3/8"
9.	AU13636	[1]	Hydraulic Hose - Fabricate	RETURN, 1 016 MM (3/4" X 40")
10.	........	[4]	Strap	( U16452 USE IF AVAILABLE)
11.	19H3131	[4]	Cap Screw	5/16" X 2"
11.	BP12232	[4]	Lock Nut
12.	AU12366	[1]	Elbow Fitting	3/4", 90°
13.	U12547	[2]	O-Ring
14.	AU11749	[1]	Elbow Fitting	3/4" X 45°
15.	........	[1]	Channel	( U15096 NO LONGER AVAILABLE)
16.	19H2633	[1]	Cap Screw	3/8" X 1-1/2"
16.	12H304	[1]	Lock Washer	3/8"
17.	AU13638	[1]	Hydraulic Hose - Fabricate	2 438.4 (3/4" X 96")
18.	28H1892	[2]	Bushing	1/8" X 5/8" (95 AND 95 SERIES-A)
19.	19H3065	[2]	Cap Screw	3/8" X 2", (95 AND 95 SERIES A)
19.	12H301	[2]	Lock Washer	1/2", (95 AND 95 SERIES A)
19.	14H812	[2]	Nut	3/8", (95 AND 95 SERIES A)
20.	........	[2]	Clamp	( U16400 NO LONGER AVAILABLE) (93 AND 93 SERIES A)
21.	U13635	[2]	Clamp
22.	19H2676	[2]	Cap Screw	HS, SAE 8, 3/8" X 1"
22.	12H304	[2]	Lock Washer	3/8"
22.	14H812	[2]	Nut	3/8"
23.	........	[2]	Strap	( U41556 NO LONGER AVAILABLE) (95 AND 95 SERIES A)
24.	24M7296	[2]	Washer	10.500 X 30 X 2.500 MM
