约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS - PRESSURE AND RETURN CIRCUIT FOR THE 94 BACKHOE WITH JD400 WHEEL LOADER [F24EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
814 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AU41205
|
[2] |
Elbow Fitting
|
|
| 2. |
U12547
|
[6] |
O-Ring
|
|
| 3. |
AU11654
|
[3] |
Fitting
|
|
| 4. |
AU11920
|
[2] |
Hydraulic Hose - Fabricate
|
|
| 5. |
AU11787
|
[1] |
Hydraulic Hose
|
|
| 6. |
JD149
|
[2] |
Adapter
|
|
| 7. |
U13055
|
[2] |
Clamp
|
|
| 8. |
AU11749
|
[1] |
Elbow Fitting
|
|
| 8. |
AU12366
|
[1] |
Elbow Fitting
|
|
| 9. |
AU40811
|
[1] |
Hydraulic Hose
|
|
| 9. |
AU13636
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 10. |
19H3065
|
[2] |
Cap Screw
|
|
| 10. |
12H304
|
[2] |
Lock Washer
|
|
| 10. |
14H812
|
[2] |
Nut
|
|
| 11. |
U41120
|
[2] |
Pipe Plug
|
|
| 12. |
AU40722
|
[1] |
Support
|
|
| 13. |
19H2676
|
[1] |
Cap Screw
|
|
| 14. |
U13415
|
[1] |
Bracket
|
|
| 15. |
U41567
|
[1] |
Strap
|
|
| 16. |
U13982
|
[2] |
Fitting
|
|
