约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS FOR THE 95 SERIES A BACKHOE WITH JD400 WHEEL LOADER [F25]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 436 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU11654	[3]	Fitting
2.	U12547	[4]	O-Ring
3.	AU13396	[1]	Tube
4.	........	[1]	Tube	( AU41039 NO LONGER AVAILABLE)
5.	........	[1]	Tube	( AU13663 NO LONGER AVAILABLE) 3 149.6 (3/4" X 124") (FOR TRACTORS SERIAL NO. 45, 199 AND BELOW)
5.	AU13638	[1]	Hydraulic Hose - Fabricate	2 438.4 (3/4" X 96") (FOR TRACTORS SERIAL NO. 45, 200 AND ABOVE)
6.	AU40811	[1]	Hydraulic Hose	1 828.8 MM (3/4" X 72")
7.	19H3065	[3]	Cap Screw	3/8" X 2"
7.	12H304	[3]	Lock Washer	3/8"
7.	14H812	[3]	Nut	3/8"
8.	U13055	[2]	Clamp
9.	AU11749	[1]	Elbow Fitting	45° (FOR TRACTORS SERIAL NO. 45, 199 AND BELOW)
9.	AU12366	[1]	Elbow Fitting	90° (FOR TRACTORS SERIAL NO. 45, 200 AND ABOVE)
10.	JD179	[2]	Union Fitting	45°
11.	U41120	[2]	Pipe Plug
12.	AU40722	[1]	Support	(FOR USE WITHOUT QUICK COUPLERS)
13.	19H1765	[1]	Cap Screw	3/8" X 1-3/4"
13.	12H304	[1]	Lock Washer	3/8"
14.	U13635	[2]	Clamp
15.	........	[2]	Strap	( U41556 NO LONGER AVAILABLE)
16.	24M7296	[2]	Washer	10.500 X 30 X 2.500 MM
17.	28H1892	[2]	Bushing	1/2" X 5/8"
18.	U41567	[1]	Strap
