约翰迪尔零件查询93 - BACKHOE OIL LINES AND FITTINGS FOR JD544 LOADER AND JD644 LOADER [G08]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
938 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT32288
|
[1] |
Tube
|
|
| 1. |
........
|
[1] |
Tube
|
|
| 2. |
AR21839
|
[6] |
Clamp
|
|
| 3. |
........
|
[1] |
Hose
|
|
| 4. |
........
|
[1] |
Hose
|
|
| 5. |
AT34857
|
[1] |
Fitting
|
|
| 6. |
........
|
[1] |
Hose
|
|
| 7. |
AT32290
|
[1] |
Hydraulic Hose
|
|
| 8. |
AT32289
|
[1] |
Fitting
|
|
| 9. |
T33040
|
[1] |
Fitting
|
|
| 10. |
R26906
|
[1] |
O-Ring
|
|
| 11. |
R36927
|
[1] |
Fitting
|
|
| 12. |
AT32287
|
[1] |
Fitting
|
|
| 13. |
T30378
|
[1] |
Isolator
|
|
| 14. |
AP23222
|
[1] |
Elbow Fitting
|
|
