Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Plate	BACK ( AT39025 NO LONGER AVAILABLE)
2.	........	[1]	Plate	(A) BACK ( T32081 NO LONGER AVAILABLE)
3.	T40419	[2]	Packing	(A)
4.	........	[1]	Housing	( T40417 NO LONGER AVAILABLE)
5.	........	[2]	Dowel Pin	( U17301 NO LONGER AVAILABLE)
6.	........	[1]	Gear	AT31209 USE IF AVAILABLE
7.	........	[1]	Seal	(A) (SUB AT39028)
8.	........	[1]	Seal	(A) (SUB AT39028)
9.	........	[1]	Seal	(A) (SUB AT39028)
10.	........	[1]	Seal	(A) (SUB AT39028)
11.	........	[1]	Spring	(A) ( U11744 NO LONGER AVAILABLE)
12.	........	[1]	Ball	(A) ( U11747 NO LONGER AVAILABLE)
13.	........	[1]	Cover	FRONT, ( AT39024 NO LONGER AVAILABLE) (SUB AT52687 IF AVAILABLE)
14.	........	[4]	Bolt	( H29856 NO LONGER AVAILABLE)
15.	AT59652	[1]	Seal	(A) (SUB FOR U13281)
16.	........	[4]	Bolt	( U13342 NO LONGER AVAILABLE)
17.	12H301	[2]	Lock Washer	1/2"
18.	19H2898	[2]	Cap Screw	1/2" X 1-1/4"
19.	........	[1]	Gear	( AT31210 USE IF AVAILABLE)
...	T43514	[1]	Gasket	(50 CC) (SUB FOR AT26340)
...	AT38801	[1]	Pump	(ALSO ORDER (2) 19H1815 AND (2) 12H301)
...	AT39028	[1]	Seal Kit	PUMP REPAIR
