| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U12547 | [6] | O-Ring | |
| 2. | AU40260 | [6] | Adapter | |
| 3. | AU40697 | [6] | Hydraulic Hose - Fabricate | 508 MM (1/2" X 20") |
| 4. | R26375 | [8] | O-Ring | |
| 5. | AH16917 | [8] | Adapter | |
| 6. | R26375 | [4] | O-Ring | (SUB FOR U10778) |
| 7. | AU11849 | [4] | Adapter | 90° |
| 8. | 15H666 | [2] | Pipe Plug | 3/8", (SUB FOR U40053, THIS APPLICATION) |
| 9. | AT33314 | [1] | Manifold | |
| 10. | 19H2472 | [2] | Cap Screw | 1/2" X 1" |
| 10. | 12H301 | [2] | Lock Washer | 1/2" |
