约翰迪尔零件查询9300 - BACKHOE STABILIZER CYLINDER [D06]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
314 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U11121
|
[4] |
Bushing
|
|
| 2. |
AT33650
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 3. |
22H1077
|
[1] |
Set Screw
|
|
| 4. |
L2235CU
|
[1] |
Lock Nut
|
|
| 5. |
U17337
|
[1] |
Wear Ring
|
|
| 6. |
U17334
|
[1] |
Piston
|
|
| 7. |
T37381
|
[1] |
Packing
|
|
| 8. |
R29463
|
[1] |
O-Ring
|
|
| 9. |
U17347
|
[1] |
Piston
|
|
| 10. |
N10193
|
[1] |
Snap Ring
|
|
| 11. |
R76801
|
[1] |
Packing
|
|
| 12. |
L2301CU
|
[1] |
O-Ring
|
|
| 12. |
A5598R
|
[1] |
O-Ring
|
|
| 13. |
L2309CU
|
[1] |
Back-Up Ring
|
|
| 13. |
R79122
|
[1] |
Back-Up Ring
|
|
| 14. |
U41578
|
[1] |
Wear Ring
|
|
| 15. |
U43233
|
[1] |
Tube
|
|
| 15. |
R80937
|
[1] |
Hydr. Cylinder Rod Guide
|
|
| 16. |
L2029CU
|
[1] |
Seal
|
|
| 17. |
AT33648
|
[1] |
Rod
|
|
| ... |
AT33647
|
[2] |
Hydraulic Cylinder
|
|
| ... |
AR105387
|
[1] |
Hydraulic Cylinder Kit
|
|
