约翰迪尔零件查询9400 - BACKHOE VALVE MOUNTING BRACKET AND COVER [A11]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
326 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT78526
|
[1] |
Support
|
|
| 2. |
U41503
|
[1] |
Bracket
|
|
| 3. |
19H2472
|
[3] |
Cap Screw
|
|
| 3. |
12H301
|
[3] |
Lock Washer
|
|
| 4. |
19H2633
|
[4] |
Cap Screw
|
|
| 4. |
24H1305
|
[4] |
Washer
|
|
| 4. |
12H304
|
[4] |
Lock Washer
|
|
| 4. |
14H812
|
[4] |
Nut
|
|
| 5. |
AU42262
|
[1] |
Box
|
|
| 6. |
U41727
|
[1] |
Valve Cover
|
|
| 7. |
U43437
|
[1] |
Valve Cover
|
|
| 8. |
19H1227
|
[6] |
Cap Screw
|
|
| 8. |
12H302
|
[6] |
Lock Washer
|
|
| 8. |
24H1287
|
[6] |
Washer
|
|
| 9. |
19H2993
|
[4] |
Cap Screw
|
|
| 9. |
12H301
|
[4] |
Lock Washer
|
|
| 9. |
14H1040
|
[4] |
Nut
|
|
| 10. |
19H3239
|
[3] |
Cap Screw
|
|
| 10. |
12H304
|
[3] |
Lock Washer
|
|
| 10. |
14H812
|
[3] |
Nut
|
|
