约翰迪尔零件查询9400 - BACKHOE MAIN FRAME AND STABILIZERS [A10]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 643 次

Pos.	Part No	Qty	Parts name	Comments
1.	U41337	[4]	Pin	(SUB FOR U41087)
2.	11M7073	[4]	Cotter Pin	8 X 63 MM
3.	AU42273	[2]	Tie Bar
4.	11M7101	[2]	Cotter Pin	8 X 80 MM
5.	U43451	[2]	Pin
6.	19H2599	[8]	Cap Screw	5/8" X 2-1/2"
7.	U43436	[4]	Strap
8.	U43435	[4]	Tapered Sleeve	OUTER
9.	U43433	[1]	Pin Fastener
10.	U43490	[2]	Pin	FRAME TO TRACTOR, (SUB FOR U43438)
11.	19H3057	[2]	Cap Screw	HS, SAE 8, 1/2" X 2-3/4"
11.	K40014	[2]	Lock Nut	(SUB FOR U12622 AND BP12214)
12.	U16050	[2]	Pin Fastener
13.	U10745	[4]	Bushing
14.	AU42250	[1]	Main Frame
15.	T33536	[4]	Bushing
16.	AU13333	[2]	Stabilizer
17.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
18.	U16008	[2]	Pin Fastener
19.	19H1820	[2]	Cap Screw	HS, SAE 8, 1/2" X 3"
19.	K40014	[2]	Lock Nut	(SUB FOR U12622 AND BP12214)
20.	U16057	[2]	Pin Fastener
21.	24H1228	[4]	Washer	1-17/32" X 2-1/2" X 0.120"
22.	U43434	[4]	Sleeve	INNER
23.	19H2633	[2]	Cap Screw	3/8" X 1-1/2"
23.	12H304	[2]	Lock Washer	3/8"
23.	14H812	[2]	Nut	3/8"
24.	AU42637	[1]	Cover
25.	U44226	[1]	Strap
26.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
