约翰迪尔零件查询9400 - BACKHOE BUCKET CYLINDER [B25]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 818 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1726	[2]	Cap Screw	3/8" X 2-1/4"
1.	12H304	[2]	Lock Washer	3/8"
1.	14H812	[2]	Nut	3/8"
2.	BU40004	[1]	Guard	RETURN TUBE (INCLUDES HARDWARE)
3.	19H3239	[1]	Cap Screw	(C) 3/8" X 1-1/4"
3.	12H304	[1]	Lock Washer	(C) 3/8"
3.	24H1305	[1]	Washer	(C) 13/32" X 13/16" X 0.065"
4.	AU12294	[1]	Tube	(C) RETURN
5.	AU11753	[1]	Union Fitting	(C)
6.	R26906	[1]	O-Ring	(A)
7.	JD7788	[1]	Lubrication Fitting	45°, 1/4"
8.	U10666	[4]	Bushing
9.	AU13286	[1]	Hydraulic Cylinder Barrel
10.	L2235CU	[1]	Lock Nut
11.	U17217	[1]	Wear Ring	(A)
12.	U17216	[1]	Piston
13.	T38193	[1]	Packing	(A) (SUB FOR U12967, THIS APPLICATION) (SUB FOR R72827)
14.	R29463	[1]	O-Ring	(A)
15.	U17219	[1]	Piston
16.	W11229	[1]	Ring
17.	R76790	[1]	Packing	(A) (SUB FOR T35851)
18.	U41822	[1]	Wear Ring	(A)
19.	U42192	[1]	Hydr. Cylinder Rod Guide	(SUB FOR AU41426)
20.	U10776	[1]	O-Ring	(A)
21.	R78993	[1]	Back-Up Ring	(A) (SUB FOR U10777, THIS APPLICATION)
22.	U10775	[1]	Snap Ring
23.	U11022	[1]	Seal	(A)
24.	U10769	[1]	Nut
25.	JD7797	[1]	Lubrication Fitting	STRAIGHT, 1/4"
26.	AU13284	[1]	Rod
...	AU13287	[1]	Hydraulic Cylinder	(C) (LESS GUARD, TUBE AND UNION FITTING)
...	RE18757	[1]	Hydraulic Cylinder Kit	(SUB FOR AT36833, AU42194, AT35937, AR99789 AND AR105354)
...	BU40274	[1]	Cylinder	(NO LONGER AVAILABLE)
