约翰迪尔零件查询9500 - BACKHOE LOCKING CONTROL VALVE [B16]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
216 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T35229
|
[1] |
Lever
|
|
| 2. |
T35233
|
[1] |
Grip
|
|
| 3. |
11M7081
|
[2] |
Cotter Pin
|
|
| 4. |
........
|
[1] |
Pin
|
|
| 5. |
T35231
|
[1] |
O-Ring
|
|
| 6. |
T35221
|
[1] |
Piston
|
|
| 7. |
T36207
|
[1] |
Spring
|
|
| 8. |
T35223
|
[1] |
Piston
|
|
| 9. |
........
|
[1] |
Cylinder Liner
|
|
| 10. |
T35232
|
[2] |
O-Ring
|
|
| 11. |
H110922
|
[2] |
Ball
|
|
| 12. |
T35227
|
[1] |
Spring
|
|
| 13. |
T35226
|
[2] |
Piston
|
|
| 14. |
T35228
|
[1] |
Base
|
|
| 15. |
T36202
|
[1] |
O-Ring
|
|
| 16. |
T35220
|
[1] |
Housing
|
|
| 17. |
P47908
|
[1] |
O-Ring
|
|
| 18. |
U40727
|
[1] |
Back-Up Ring
|
|
| 19. |
AT35910
|
[1] |
Valve
|
|
| 20. |
AT36560
|
[1] |
Control Valve
|
|
