约翰迪尔零件查询9500 - BACKHOE LOCKING CONTROL VALVE [B17]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
858 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT114222
|
[1] |
Pressure Relief Valve
|
|
| 2. |
R26375
|
[1] |
O-Ring
|
|
| 3. |
P50883
|
[1] |
Ring
|
|
| 4. |
R33259
|
[1] |
O-Ring
|
|
| 5. |
R26906
|
[2] |
O-Ring
|
|
| 6. |
T101764
|
[2] |
Back-Up Ring
|
|
| 7. |
T101763
|
[4] |
Shim
|
|
| 8. |
AT107902
|
[1] |
Solenoid Hydraulic Valve
|
|
| 9. |
........
|
[1] |
Spool Valve
|
|
| 10. |
........
|
[1] |
Housing
|
|
| 11. |
........
|
[1] |
Fitting
|
|
| 12. |
AT103536
|
[1] |
Solenoid Valve
|
|
| 13. |
........
|
[1] |
Housing
|
|
| 14. |
........
|
[1] |
Relief Valve
|
|
| 15. |
19M7319
|
[2] |
Screw
|
|
| 16. |
24H1923
|
[4] |
Washer
|
|
| 17. |
14M7272
|
[2] |
Nut
|
|
| 18. |
AT107902
|
[1] |
Solenoid Hydraulic Valve
|
|
