现代零件查询15/18/20LC-7M MCV INLET SECTIONEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
653 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
XKBF-01049
|
[1] |
INLET BLOCK ASSY
|
|
| 11. |
XKBF-01061
|
[1] |
INLET BLOCK
|
|
| 12. |
XKBF-00931
|
[4] |
PLUG
|
|
| 13. |
XKBF-01062
|
[1] |
MAIN RELIEF VALVE
|
|
| 13-1. |
XKBF-01065
|
[1] |
PILOT SEAT
|
|
| K13-2. |
XKBF-01066
|
[1] |
O-RING
|
|
| K13-3. |
XKBF-01067
|
[2] |
O-RING
|
|
| 13-4. |
XKBF-01068
|
[1] |
MAIN POPPET
|
|
| K13-5. |
XKBF-01069
|
[1] |
O-RING
|
|
| 13-6. |
XKBF-01070
|
[1] |
MR SOCKET
|
|
| N13-7. |
XKBF-01071
|
[1] |
MAIN SPRING
|
|
| 13-8. |
XKBF-01072
|
[1] |
PISTON
|
|
| 13-9. |
XKBF-01073
|
[1] |
BODY
|
|
| K13-10. |
XKBF-01074
|
[1] |
O-RING
|
|
| K13-11. |
XKBF-01075
|
[1] |
O-RING
|
|
| N13-12. |
XKBF-01076
|
[1] |
PILOT POPPET
|
|
| N13-13. |
XKBF-01077
|
[1] |
PILOT SPRING
|
|
| N13-14. |
XKBF-01078
|
[1] |
ADJUST SCREW
|
|
| K13-15. |
XKBF-01079
|
[1] |
O-RING
|
|
| N13-16. |
XKBF-01080
|
[1] |
LOCK NUT
|
|
| K13-17. |
XKBF-01081
|
[1] |
BACKUP RING
|
|
| K13-18. |
XKBF-01082
|
[1] |
BACKUP RING
|
|
| K13-19. |
XKBF-01083
|
[1] |
BACKUP RING
|
|
| K13-20. |
XKBF-01084
|
[1] |
BACKUP RING
|
|
| 14. |
XKBF-01413
|
[1] |
SOLENOID V/V
|
|
| 15. |
XKBF-00579
|
[1] |
PLUG
|
|
| K16. |
XKBF-00578
|
[1] |
O-RING
|
|
| K17. |
XKBF-00582
|
[1] |
O-RING
|
|
| K. |
XKBF-01085
|
[1] |
SEAL KIT
|
|
| K. |
XKBF-01064
|
[1] |
SEAL KIT
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
