现代零件查询15/18/20LC-7M MCV OUTLET SECTIONEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
606 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
XKBF-01054
|
[1] |
OUTLET BLOCK ASSY
|
|
| N1. |
XKBF-01103
|
[1] |
OUTLET BLOCK
|
|
| 2. |
XKBF-01104
|
[1] |
SECONDARY RELIEF V/V
|
|
| N2-1. |
XKBF-01105
|
[1] |
PILOT SEAT
|
|
| K2-2. |
XKBF-01106
|
[1] |
O-RING
|
|
| N2-3. |
XKBF-01107
|
[1] |
MAIN POPPET
|
|
| NK2-4. |
XKBF-01108
|
[1] |
BACKUP RING
|
|
| NK2-5. |
XKBF-01109
|
[1] |
O-RING
|
|
| N2-6. |
XKBF-01110
|
[1] |
SOCKET
|
|
| N2-7. |
XKBF-01071
|
[1] |
MAIN SPRING
|
|
| N2-8. |
XKBF-01111
|
[1] |
PISTON
|
|
| N2-9. |
XKBF-01112
|
[1] |
BODY
|
|
| K2-10. |
XKBF-00989
|
[1] |
O-RING
|
|
| K2-11. |
XKBF-01113
|
[1] |
RING-BACK UP
|
|
| K2-12. |
XKBF-00937
|
[1] |
O-RING
|
|
| N2-13. |
XKBF-01076
|
[1] |
PILOT POPPET
|
|
| N2-14. |
XKBF-01077
|
[1] |
PILOT SPRING
|
|
| N2-15. |
XKBF-01078
|
[1] |
ADJUST SCREW
|
|
| K2-16. |
XKBF-01079
|
[1] |
O-RING
|
|
| N2-17. |
XKBF-01080
|
[1] |
LOCK NUT
|
|
| K. |
XKBF-01114
|
[1] |
SEAL KIT
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
