| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19H2855 | [2] | Cap Screw | 3/8" X 3-1/4" |
| 2. | U40360 | [2] | Pin | STABILIZER, CYLINDER UPPER |
| 3. | T11234 | [2] | Lock Nut | 3/8" |
| 4. | 11H223 | [4] | Cotter Pin | 3/8" X 2" |
| 4. | 11H223 | [4] | Cotter Pin | 3/8" X 2" |
| 5. | 24H1498 | [4] | Washer | 1-9/32" X 2-1/8" X 0.120" |
| 5. | 24H1498 | [4] | Washer | 1-9/32" X 2-1/8" X 0.120" |
| 6A. | T43383 | [2] | Pin | PIVOT |
| 6A. | T43383 | [2] | Pin | |
| 6B. | T59461 | [2] | Pin | (SUB T43383, (2) 11H223 AND (2) 24H1498) |
| 7. | T59447 | [4] | Snap Ring |
