约翰迪尔零件查询9550 - BACKHOE BOOM PIVOT AND SWING LINKAGE [A11]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
557 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
JD7806
|
[2] |
Lubrication Fitting
|
|
| 2. |
U43212
|
[2] |
Bolt
|
|
| 3. |
U43180
|
[4] |
Spacer
|
|
| 4. |
U43179
|
[4] |
Tapered Sleeve
|
|
| 5. |
T50103
|
[2] |
Pin
|
|
| 6. |
A3581R
|
[1] |
Spring Locking Pin
|
|
| 7. |
T68041
|
[1] |
Pin
|
|
| 8. |
U40304
|
[1] |
Bushing
|
|
| 9. |
T33688
|
[4] |
Bushing
|
|
| 10. |
U40305
|
[1] |
Bushing
|
|
| 11. |
AT46838
|
[1] |
Frame
|
|
| 12. |
28316
|
[1] |
Spring Locking Pin
|
|
| 13. |
U43218
|
[1] |
Pin
|
|
| 14. |
11M7030
|
[1] |
Cotter Pin
|
|
| 15. |
JD7797
|
[4] |
Lubrication Fitting
|
|
