约翰迪尔零件查询9550 - BACKHOE HEAVY-DUTY BUCKETS [A22]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 758 次

Pos.	Part No	Qty	Parts name	Comments
1.	U42740	[1]	Cutting Edge	SIDE, R.H.
2.	U42753	[1]	Cutting Edge	457 MM (18") BUCKET
2.	U42752	[1]	Cutting Edge	609 MM (24") BUCKET
3.	T40910	[AR]	Pin	(3 USED WITH 457 MM (18") BUCKET, 4 USED WITH 609 MM (24") BUCKET) (SUB FOR U13927)
4.	U43792	[AR]	Bucket Tooth Adapter	(SUB FOR (AR) U42750) (3 USED WITH 457 MM (18") BUCKET, 4 USED WITH 609 MM (24") BUCKET)
5.	U42751	[AR]	Point	(3 USED WITH 18" (457 MM) BUCKET, 4 USED WITH 24" (609 MM) BUCKET)
6.	U42741	[1]	Cutting Edge	SIDE, L.H.
7.	........	[1]	Backhoe Bucket	HEAVY-DUTY 457 MM (18") LONG ( AT37733 NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS)
7.	........	[1]	Backhoe Bucket	HEAVY-DUTY 610 MM (24") LONG (USE AT37734 IF AVAILABLE) (SUB AT114252)
8.	........	[1]	Plate	(SUB AT36087)
9.	U42738	[2]	Bushing
10.	U42737	[4]	Bushing
11.	........	[1]	Plate	(SUB AT36087)
12.	........	[AR]	Tooth	(3 USED WITH 457 MM (18") BUCKET, 4 USED WITH 609 MM (24") BUCKET) ( AU41838 - NO LONGER AVAILABLE) (SUB T40910, U43792 AND U42751)
13.	AT36087	[1]	Plate
