| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T38783 | [1] | Bucket Tooth Adapter | DIMENSION A=8-3/8"; B=1-1/8"; C=9-7/8"; D=30 DEGREES; WEIGHT=12.3 LBS. |
| 1. | U16087 | [1] | Bucket Tooth Adapter | DIMENSION A=7-1/2"; B=1-1/2"; C=8-1/8"; D=35 DEGREES; WEIGHT=9.3 LBS. |
| ... | T29887 | [1] | Tooth | WEIGHT=4.5 LBS. |
| ... | TP160 | [1] | Pin | |
| ... | TF160L | [1] | Tooth | LONG |
