| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AM125039 | [1] | Bracket | (A) |
| 2. | M132218 | [1] | Drawbar | (A) |
| 3. | 19M7789 | [4] | Screw | M12 X 30 (A) (HS, HEAD MARKED 10.9) |
| 4. | M137028 | [2] | Pin Fastener | (A) |
| 5. | M40461 | [2] | Spring Locking Pin | (A) |
| 6. | ........ | [1] | Pin Fastener | (A) |
| 7. | 34M7042 | [1] | Spring Pin | 6 X 40 MM (A) |
| 8. | AM127220 | [1] | Quick Lock Pin | (A) |
| 9. | A15147 | [1] | Spring Locking Pin | (A) |
| 10. | 19M8832 | [4] | Screw | M14 X 30 (A) (HS, HEAD MARKED 10.9) |
| ... | LVB25359 | [1] | Kit | DRAWBAR HITCH (INCLUDES PARTS MARKED (A)) |
