约翰迪尔零件查询110 - BACKHOE, LOADER Firewall ( - 310999)EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 273 次

Pos.	Part No	Qty	Parts name	Comments
1.	14M7396	[12]	Lock Nut	M8 (SUB FOR AM131736)
2.	M133730	[1]	Latch
3.	14M7426	[2]	Lock Nut	M8
4.	14M7400	[4]	Lock Nut	M10
5.	19M7775	[2]	Screw	M6 X 16 (HS, HEAD MARKED 10.9)
6.	19M7796	[2]	Screw	M6 X 30 (HS, HEAD MARKED 10.9)
7.	19M7804	[6]	Screw	M10 X 40 (HS, HEAD MARKED 10.9)
8.	19M7865	[6]	Screw	M8 X 16 (HS, HEAD MARKED 10.9)
9.	19M7866	[5]	Screw	M8 X 20 (HS, HEAD MARKED 10.9)
10.	19M7867	[8]	Screw	M8 X 25 (HS, HEAD MARKED 10.9)
11.	24H1630	[8]	Washer	1-1/8" X 1-7/8" X 0.060"
12.	24M7315	[4]	Washer	17 X 50 X 3 MM
13.	L79226	[1]	Clip
14.	M63199	[2]	Rivet
15.	LVA11441	[1]	Latch
16.	LVA11056	[1]	Bracket
17.	LVA11261	[1]	Bracket
18.	LVA11046	[1]	Frame
19.	LVA12884	[1]	Firewall
20.	LVU12087	[1]	Bracket
21.	LVU12088	[2]	Bushing
22.	LVU12089	[2]	Isolator
23.	M133729	[1]	Cover
24.	LVU10922	[1]	Cowl
25.	LVU12198	[1]	Bracket
26.	LVU12203	[2]	Isolator
27.	LVU12204	[1]	Isolator
28.	LVU13556	[4]	Bolt	FUEL TANK MOUNTING
29.	LVU12328	[1]	Label
30.	LVU12326	[1]	Isolator
31.	LVU12327	[1]	Isolator
32.	LVA16083	[6]	Isolator	(SUB FOR M133098)
33.	M133440	[6]	Washer
34.	LVA12234	[1]	Bracket
35.	03M7184	[4]	Bolt	M8 X 20
