约翰迪尔零件查询210C - BACKHOE, LOADER Multi-Purpose Bucket Cylinder (770928 - )EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
180 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT190881
|
[1] |
Barrel
|
|
| 2. |
H29619
|
[1] |
Lock Nut
|
|
| 3. |
........
|
[2] |
Wear Ring
|
|
| 4. |
........
|
[1] |
Seal
|
|
| 5. |
T163117
|
[1] |
Piston
|
|
| 6. |
........
|
[1] |
Seal
|
|
| 7. |
T163116
|
[1] |
Hydr. Cylinder Rod Guide
|
|
| 8. |
........
|
[1] |
Back-Up Ring
|
|
| 9. |
........
|
[1] |
O-Ring
|
|
| 10. |
........
|
[1] |
Seal
|
|
| 11. |
JD7797
|
[1] |
Lubrication Fitting
|
|
| 12. |
T163118
|
[1] |
Hydraulic Cylinder Rod
|
|
| 13. |
........
|
[1] |
O-Ring
|
|
| 14. |
........
|
[1] |
Cylinder
|
|
| 15. |
AT190898
|
[1] |
Packing
|
|
