约翰迪尔零件查询210C - BACKHOE, LOADER Multi-Purpose Bucket Cylinder and Repair Kit (Replacement Cylinder)EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
581 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
........
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 2. |
T14065
|
[1] |
O-Ring
|
|
| 3. |
........
|
[2] |
Ring
|
|
| 4. |
H177854
|
[1] |
Snap Ring
|
|
| 5. |
........
|
[1] |
O-Ring
|
|
| 6. |
H180927
|
[1] |
Snap Ring
|
|
| 7. |
........
|
[1] |
O-Ring
|
|
| 8. |
14H1112
|
[1] |
Nut
|
|
| 9. |
........
|
[1] |
Wear Ring
|
|
| 10. |
........
|
[1] |
O-Ring
|
|
| 11. |
........
|
[1] |
Piston
|
|
| 12. |
........
|
[1] |
Piston Ring
|
|
| 13. |
........
|
[1] |
Rod
|
|
| 14. |
H180965
|
[1] |
Bushing
|
|
| 15. |
........
|
[1] |
Hydr. Cylinder Rod Guide
|
|
| 16. |
H152203
|
[1] |
Seal
|
|
| 17. |
........
|
[1] |
Seal
|
|
| 18. |
AH210737
|
[1] |
Hydraulic Cylinder
|
|
| 19. |
AH209022
|
[1] |
Hydraulic Cylinder Kit
|
|
