| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T36012 | [1] | Spring | |
| 2. | U13616 | [1] | Pressure Relief Valve | |
| 3. | H63283 | [1] | O-Ring | (K: KIT AT160684 RELIEF VALVE SEAL KIT) |
| 4. | T35984 | [2] | Back-Up Ring | (K: KIT AT160684 RELIEF VALVE SEAL KIT) |
| 5. | T35985 | [1] | Back-Up Ring | (K: KIT AT160684 RELIEF VALVE SEAL KIT) |
| 6. | ........ | [AR] | Solid Shim | (SUB AT101901) |
| 7. | W19903 | [2] | O-Ring | (K: KIT AT160684 RELIEF VALVE SEAL KIT) |
| 8. | ........ | [1] | Poppet | (SUB AT101901) |
| 9. | ........ | [1] | Spring | (SUB AT101901) |
| 10. | ........ | [1] | Cap | (SUB AT101901) |
| 11. | ........ | [1] | Case | (SUB AT101901) |
| 12. | T77932 | [1] | O-Ring | (K: KIT AT160684 RELIEF VALVE SEAL KIT) (SUB FOR Z29304) |
| 13. | AT101901 | [1] | Pressure Relief Valve | 3 447 KPA (500 PSI) (BOTTOM PORT) |
