约翰迪尔零件查询210C - BACKHOE, LOADER LIFT SECTION POSITIONER ( - 752372)EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
980 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H3554
|
[2] |
Screw
|
|
| 2. |
T104774
|
[2] |
Locking Collar
|
|
| 2. |
T104774
|
[1] |
Locking Collar
|
|
| 2. |
T142863
|
[1] |
Round Retainer
|
|
| 3. |
A11318
|
[1] |
Snap Ring
|
|
| 4. |
T118653
|
[1] |
Cap
|
|
| 5. |
T125548
|
[1] |
Spring
|
|
| 6. |
R63075
|
[4] |
Ball
|
|
| 7. |
T142864
|
[1] |
Sleeve
|
|
| 7. |
T142864
|
[1] |
Sleeve
|
|
| 8. |
T125549
|
[1] |
Spring
|
|
| 9. |
T104781
|
[1] |
Sleeve
|
|
| 9. |
T142865
|
[1] |
Sleeve
|
|
| 10. |
U15242
|
[1] |
O-Ring
|
|
| 10. |
T142866
|
[1] |
Packing
|
|
| 11. |
T104782
|
[1] |
Follower
|
|
| 12. |
T104783
|
[1] |
O-Ring
|
|
| 12. |
U11296
|
[2] |
O-Ring
|
|
| 12. |
T57246
|
[1] |
O-Ring
|
|
| 13. |
AT114502
|
[1] |
Retainer
|
|
| 13. |
AT167591
|
[1] |
Retainer
|
|
