约翰迪尔零件查询210C - BACKHOE, LOADER Valve End Plates (Three-Point Hitch Valve) ( - 752372)EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询210C - BACKHOE, LOADER Valve End Plates (Three-Point Hitch Valve) ( - 752372)EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 362 次

Pos.	Part No	Qty	Parts name	Comments
1.	T113058	[1]	End Plate	LEFT
2.	T44948	[1]	O-Ring	(K: KIT AT160684 RELIEF VALVE SEAL KIT)
3.	T127155	[1]	O-Ring	(K: KIT AT160684 RELIEF VALVE SEAL KIT) (SUB FOR U15242, THIS APPLICATION)
4.	T75972	[1]	Back-Up Ring	(K: KIT AT160684 RELIEF VALVE SEAL KIT) (SUB FOR T47769, THIS APPLICATION)
5.	........	[2]	Back-Up Ring	( T47769 - NO LONGER REQUIRED)
6.	........	[1]	Seal Kit	( AT75601 - NO LONGER AVAILABLE)
7.	R28782	[1]	O-Ring
8.	14H1076	[3]	Nut	3/8"
9.	19H1925	[3]	Cap Screw	3/8" X 4-1/4" (SINGLE-FUNCTION)
9.	T81407	[3]	Cap Screw	(FOUR-FUNCTION)
10.	T49819	[4]	O-Ring	(K1) (SINGLE-FUNCTION) (SUB FOR T106368)
10.	T49819	[10]	O-Ring	(K1) (FOUR-FUNCTION) (SUB FOR T106368)
11.	T142419	[4]	O-Ring	(K1) (SINGLE-FUNCTION) (SUB FOR T113021)
11.	T142419	[10]	O-Ring	(K1) (FOUR-FUNCTION) (SUB FOR T113021)
12.	R27474	[1]	Drain Plug
13.	R51031	[1]	Fitting
14.	R26906	[1]	O-Ring
15.	AT148668	[1]	Cover	(SUB FOR AT101887 ) (ALSO ORDER AT160682)RIGHT
16.	AT62368	[1]	Fitting Plug
