| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AR70633 | [3] | Piston Ring Kit | (A) (SUB FOR AR55758) (SET OF 3 RINGS) (DIESEL) |
| 2. | R51112 | [3] | Snap Ring | STANDARD (SET OF 3 RINGS) (DIESEL) |
| 3. | T23482 | [3] | Piston Pin | (DIESEL) |
| 4. | T23481 | [3] | Piston | (A) (DIESEL) |
| 5. | T23471 | [3] | Bushing | CONNECTING ROD (DIESEL) |
| 6. | RE19733 | [3] | Connecting Rod | (DIESEL) (SUB FOR AT18005) |
| 7. | T20009 | [6] | Cap Screw | (SUB R74194) (DIESEL) |
| 7. | R74194 | [6] | Screw | (DIESEL) (USE WITH AT18005) |
| 7. | R80033 | [6] | Cap Screw | (DIESEL) (USE WITH RE19733) |
| 8. | AT21138 | [3] | Bearing | STANDARD (DIESEL) (SET OF (2) T20011) |
| 8. | ........ | [3] | Bearing | ( AT21122 NO LONGER AVAILABLE) .05 MM (.002") UNDERSIZE (DIESEL) (SET OF (2) T23566) |
| 8. | AT21124 | [3] | Bearing | .254 MM (.010") UNDERSIZE (DIESEL) (SET OF (2) T23568) |
| 8. | AT21126 | [3] | Bearing | .508 MM (.020") UNDERSIZE (DIESEL) (SET OF (2) T23570) |
| 8. | AT21128 | [3] | Bearing | .762 MM (.030") UNDERSIZE (DIESEL) (SET OF (2) T23572) |
| 9. | AR70633 | [3] | Piston Ring Kit | (B) (SUB FOR AR55758) (SET OF 3 RINGS) (GASOLINE) |
| 10. | T23504 | [3] | Piston | (B) STANDARD (GASOLINE) |
| 10. | T23504 | [3] | Piston | (SUB FOR T25027) STANDARD HIGH ALTITUDE (GASOLINE) |
| 11. | T526T | [3] | Bushing | (GASOLINE) |
| 12. | AT18147 | [3] | Connecting Rod | (GASOLINE) |
| 13. | T19173 | [6] | Bolt | (GASOLINE) |
| 14. | AT10123 | [3] | Bearing | STANDARD (GASOLINE) (SET OF (2) T18925) |
| 14. | AT21116 | [3] | Bearing | .05 MM (.002") UNDERSIZE (GASOLINE) (SET OF (2) T23560) |
| 14. | AT21117 | [3] | Bearing | .254 MM (.010") UNDERSIZE (GASOLINE) (SET OF (2) T23561) |
| 14. | AT21119 | [3] | Bearing | .508 MM (.020") UNDERSIZE (GASOLINE) (SET OF (2) T23563) |
| 14. | AT10519 | [3] | Bearing | .762 MM (.030") UNDERSIZE (GASOLINE) (SET OF (2) T18939) |
| 15. | T18838 | [3] | Piston Pin | (GASOLINE) |
| ... | AR71590 | [1] | Piston-Liner Kit | (CONTAINS CYLINDER LINER WITH 0-RINGS AND PISTON WITH PISTON RINGS) (GASOLINE) |
| ... | AR71591 | [1] | Piston-Liner Kit | (CONTAINS CYLINDER LINER WITH 0-RINGS AND PISTON WITH PISTON RINGS) (DIESEL) |
