Pos.	Part No	Qty	Parts name	Comments
1.	T20155	[1]	Gasket
2.	R122226	[2]	Stud	(SUB FOR R122226)
3.	24H1304	[AR]	Washer	13/32" X 23/32" X 0.120"
4.	19H2458	[2]	Cap Screw	3/8" X 3"
5.	14H812	[2]	Nut	3/8"
6.	19H2549	[10]	Cap Screw	3/8" X 1-7/8"
7.	T20364	[1]	Gasket	(SUB R78366)
7.	R78366	[1]	Gasket	(SUB FOR R69260)
8.	R126041	[1]	Cover	(SUB FOR T20362) INJECTION PUMP GEAR
9.	R122618	[2]	Screw	(SUB FOR 19H2284, THIS APPLICATION)
10.	19H3031	[2]	Cap Screw	3/8" X 2-1/2"
11.	R83169	[1]	Valve	OIL PRESSURE RELIEF, (SUB FOR R51516)
12.	T27658	[1]	Spring
13.	24H1290	[AR]	Washer	21/64" X 3/4" X 0.035"
14.	T27657	[1]	Fitting Plug
15.	A4827R	[1]	Washer	ALUMINUM
16.	AR58196	[1]	Cover	(MARKED R52880) (ALSO ORDER T20272, T20273, (3) 19H2284, 19H1726, (4) 24H1304 AND 15H275)
17.	15H275	[1]	Pipe Plug	HEX. CTSK., 1/4"
18.	T20273	[1]	Gasket
19.	T20272	[1]	Cover
20.	24H1304	[3]	Washer	13/32" X 23/32" X 0.120"
21.	19H2284	[3]	Cap Screw	3/8" X 7/8"
