约翰迪尔零件查询300B - BACKHOE, LOADER TIMING GEAR COVER (GASOLINE) [01C04]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
193 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T20154
|
[1] |
Gasket
|
|
| 2. |
24H1304
|
[16] |
Washer
|
|
| 3. |
19H2458
|
[2] |
Cap Screw
|
|
| 4. |
R122226
|
[2] |
Stud
|
|
| 5. |
14H812
|
[2] |
Nut
|
|
| 6. |
T20146
|
[1] |
Bushing
|
|
| 7. |
T16468
|
[1] |
Dowel Pin
|
|
| 8. |
19H3267
|
[1] |
Cap Screw
|
|
| 9. |
19H2549
|
[5] |
Cap Screw
|
|
| 10. |
19H3031
|
[2] |
Cap Screw
|
|
| 11. |
R83169
|
[1] |
Valve
|
|
| 12. |
T27658
|
[1] |
Spring
|
|
| 13. |
T27657
|
[1] |
Fitting Plug
|
|
| 14. |
A4827R
|
[1] |
Washer
|
|
| 15. |
24H1290
|
[1] |
Washer
|
|
| 16. |
AT19508
|
[1] |
Cover
|
|
| 17. |
15H275
|
[1] |
Pipe Plug
|
|
| 18. |
T20273
|
[1] |
Gasket
|
|
| 19. |
T20272
|
[1] |
Cover
|
|
| 20. |
19H2284
|
[3] |
Cap Screw
|
|
| 21. |
19H2549
|
[1] |
Cap Screw
|
|
