约翰迪尔零件查询300B - BACKHOE, LOADER RADIATOR (WITHOUT OIL COOLER) [01C20]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
325 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T11234
|
[2] |
Lock Nut
|
|
| 2. |
24H1305
|
[2] |
Washer
|
|
| 3. |
R61460
|
[1] |
Rod
|
|
| 4. |
24H1122
|
[1] |
Washer
|
|
| 5. |
19H2664
|
[1] |
Cap Screw
|
|
| 6. |
AT27585
|
[1] |
Cap
|
|
| 7. |
AT48171
|
[1] |
Radiator
|
|
| 8. |
AR21999
|
[4] |
Hose Clamp
|
|
| 9. |
T23533
|
[1] |
Hose
|
|
| 9. |
R38481
|
[1] |
Hose
|
|
| 9. |
T22496
|
[1] |
Hose
|
|
| 10. |
T22500
|
[1] |
Hose
|
|
| 10. |
T22497
|
[1] |
Hose
|
|
| 11. |
19H2458
|
[2] |
Cap Screw
|
|
| 12. |
R34352
|
[2] |
Compression Spring
|
|
| 13. |
T22381
|
[2] |
Washer
|
|
| 14. |
AT13740
|
[1] |
Drain Valve
|
|
| 15. |
14H785
|
[1] |
Nut
|
|
| 16. |
12H303
|
[1] |
Lock Washer
|
|
| ... |
T11847
|
[1] |
Sealant
|
|
