约翰迪尔零件查询300B - BACKHOE, LOADER WATER PUMP (DIESEL) [01C23]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 960 次

Pos.	Part No	Qty	Parts name	Comments
1.	T20243	[1]	Gasket
2.	T20270	[1]	Cover
3.	R97455	[1]	Gasket	(SUB FOR T20271)
4.	T30897	[1]	Impeller	(SUB FOR T30897 OR R94419)
5.	T27261	[1]	Seal	(SUB AR101549)
6.	JD9257	[1]	Ball Bearing
7.	T19651	[1]	Hose Fitting
8.	R48997	[1]	Housing	(SUB AT27018 AND RE19944) DIESEL
8.	R51039	[1]	Housing	(SUB AT27018 AND RE19944) DIESEL
9.	R97758	[1]	V-Belt	(SUB FOR T20334)
10.	T23628	[1]	Pulley	(SUB FOR T30721) (ALSO ORDER (4) 19H3467)
11.	19H1912	[2]	Cap Screw	3/8" X 3-1/2"
12.	12H304	[4]	Lock Washer	3/8"
13.	14H812	[1]	Nut	3/8"
14.	19H3065	[1]	Cap Screw	3/8" X 2"
15.	19H1726	[1]	Cap Screw	3/8" X 2-1/4"
16.	R108404	[1]	Strap	ALTERNATOR ADJUSTING, (SUB FOR T20204 AND R107734)
17.	T25701	[1]	Stud
18.	AT34754	[1]	Fan
19.	19H3385	[1]	Cap Screw	1/2" X 1-1/8"
20.	19H2127	[4]	Cap Screw	5/16" X 7/8"
21.	24H1304	[1]	Washer	13/32" X 23/32" X 0.120"
22.	12H304	[1]	Lock Washer	3/8"
23.	15H584	[1]	Pipe Plug	SQ. HD., 1/2" (WITHOUT CAB)
23.	T37041	[1]	Elbow Fitting	90° (WITH CAB)
24.	AR41691	[1]	Seal Kit
25.	AR101549	[1]	Seal Kit
26.	T30720	[1]	Hub	(SUB FOR R62371) (USE WITH T30721, NOT REQUIRED WITH T23628)
27.	AT29619	[1]	Water Pump	(MARKED R48997) (SUB RE19944) (ALSO ORDER T30721, T23628, T20270, R97455, (2) 19H2545 AND (4) 19H3467)
27.	AR55094	[1]	Water Pump	(MARKED R51039) (SUB RE19944) (ALSO ORDER T30721, T23628, T20270, R97455, (2) 19H2545 AND (4) 19H3467)
27.	AT27018	[1]	Water Pump	(MARKED R48997)
