约翰迪尔零件查询300B - BACKHOE, LOADER FUEL TANK ASSEMBLY [01D04]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
978 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T27474
|
[1] |
Tube
|
|
| 2. |
15H638
|
[1] |
Pipe Plug
|
|
| 3. |
T32231
|
[1] |
Clamp
|
|
| 4. |
AT22089
|
[1] |
Fitting
|
|
| 5. |
AT20911
|
[1] |
Filler Cap
|
|
| 6. |
R39615
|
[1] |
Washer
|
|
| 7. |
T36247
|
[1] |
Grommet
|
|
| 8. |
AR72996
|
[1] |
Fuel Tank
|
|
| 9. |
24H1305
|
[4] |
Washer
|
|
| 10. |
19H2676
|
[4] |
Cap Screw
|
|
| 11. |
AT20912
|
[1] |
Sender
|
|
| 12. |
R27181
|
[1] |
Gasket
|
|
| 13. |
F2506R
|
[1] |
Cover
|
|
| 14. |
37H47
|
[5] |
Screw
|
|
| 15. |
T33232
|
[2] |
Stop
|
|
| 16. |
19H3385
|
[2] |
Cap Screw
|
|
| 17. |
24H1625
|
[2] |
Washer
|
|
| 18. |
AR96448
|
[1] |
Fuel Line
|
|
| 19. |
A4881R
|
[1] |
Clip
|
|
| 20. |
12H304
|
[1] |
Lock Washer
|
|
| 21. |
19H2038
|
[1] |
Cap Screw
|
|
| 22. |
AT35139
|
[1] |
Hand Operated Valve
|
|
| 23. |
T42632
|
[1] |
Fuel Filter
|
|
