| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19H3483 | [2] | Cap Screw | 3/8" X 1-1/8" |
| 2. | 12H304 | [2] | Lock Washer | 3/8" |
| 3. | T10079 | [1] | Gasket | |
| 4. | RE19402 | [1] | Carburetor | (ALSO ORDER RE19408 SOLENOID ASSEMBLY) (SUB FOR AT23000, MARVEL-SCHEBLER NO.TSX-904) |
| 5. | AT29317 | [1] | Fuel Line | |
| 6. | T30738 | [1] | Elbow Fitting | 90° |
| 7. | RE36905 | [1] | Fuel Pump | (USE IF AVAILABLE) (SUB FOR AR64120) |
| 7. | RE43274 | [1] | Fuel Pump | (SUB FOR RE36905) (ALSO ORDER R27285) |
| 8. | T27860 | [2] | Washer | ALUMINUM (SUB FOR R20498, THIS APPLICATION) |
| 9. | 19H1849 | [2] | Cap Screw | 5/16" X 1-1/4" |
| 10. | R520618 | [1] | Gasket | (SUB FOR R27285, R97350) |
| 11. | AR26674 | [1] | Elbow Fitting | 90° |
