约翰迪尔零件查询300B - BACKHOE, LOADER ENGINE AND PTO CLUTCH AND FLYWHEEL (WITH CONTINUOUS DRIVEN PTO) (WITHOUT REVERSER) [01E20]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询300B - BACKHOE, LOADER ENGINE AND PTO CLUTCH AND FLYWHEEL (WITH CONTINUOUS DRIVEN PTO) (WITHOUT REVERSER) [01E20]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 269 次

Pos.	Part No	Qty	Parts name	Comments
1.	T20088	[1]	Gear	(142 TEETH)
2.	AR67977	[1]	Flywheel	(MARKED R56899)
3.	19H2898	[4]	Cap Screw	HS, SAE 8, 1/2" X 1-1/4"
4.	AR63695	[1]	Clutch Disk
5.	T23008	[3]	Bolt	SQ. HD.
6.	T22194	[1]	Clutch Plate
7.	R26638	[6]	Spring
8.	T22927	[9]	Spring	OUTER
9.	R27033	[9]	Round Retainer
10.	T22195	[1]	Clutch Plate
11.	AL19092	[1]	Clutch	(SUB FOR AT21675) (DIESEL)
11.	RE31382	[1]	Clutch Disk	(GASOLINE) (SUB FOR AT20916)
12.	T27706	[1]	Cover
13.	T27708	[3]	Pin Fastener	HEADED
14.	19H3385	[6]	Cap Screw	1/2" X 1-1/8"
15.	14H774	[6]	Nut	3/8"
16.	AR43065	[1]	Thrust Bearing
17.	R51469	[1]	Planet Pinion Carrier
18.	T21450	[1]	Extension Spring
19.	T21446	[1]	Bushing
20.	T21999	[1]	Fork
21.	AT19837	[1]	Shaft
22.	34H353	[2]	Spring Pin	3/8" X 1-3/4"
23.	T27707	[3]	Spring
24.	24H1325	[6]	Washer	15/32" X 59/64" X 0.065"
25.	T21932	[3]	Bar	LEVER, CLUTCH OPERATING
26.	T24381	[3]	Dowel Pin
27.	R96514	[3]	Lever	CLUTCH, OPERATING, (SUB FOR T22197)
28.	11M7059	[3]	Cotter Pin	3.200 X 20 MM
