现代零件查询20L/25L/30L-7 CARRIER SUB ASSY(NEW)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
645 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
DRIVE AXLE ASSY
|
|
| -3. |
XKCF-00580
|
[1] |
CARRIER SUB ASSY
|
|
| -3. |
XKCF-01104
|
[1] |
CARRIER SUB ASSY
|
|
| -3. |
XKCF-00580
|
[1] |
CARRIER SUB ASSY
|
|
| -3. |
XKCF-01104
|
[1] |
CARRIER SUB ASSY
|
|
| -3. |
XKCF-00580
|
[1] |
CARRIER SUB ASSY
|
|
| -3. |
XKCF-01104
|
[1] |
CARRIER SUB ASSY
|
|
| 1. |
XKCF-00506
|
[1] |
CARRIER CASE-CAP ASSY
|
|
| 1-1. |
XKCF-00507
|
[1] |
CASE-CARRIER
|
|
| 1-2. |
XKCF-00508
|
[2] |
CAP-CARRIER
|
|
| 1-3. |
XKCF-00509
|
[4] |
BOLT-SOCKET
|
|
| 1-4. |
XKCF-00510
|
[2] |
STEEL BALL
|
|
| 1-5. |
XKCF-00131
|
[4] |
BALL-STEEL
|
|
| 2. |
@
|
[1] |
DIFFERENTIAL SUB ASSY
|
|
| 3. |
XKCF-00512
|
[AR] |
BEVEL SET
|
|
| N3-1. |
XKCF-00513
|
[1] |
RING GEAR-SPIRAL
|
|
| N3-2. |
XKCF-00514
|
[1] |
SHAFT-PINION
|
|
| 4. |
XKCF-00515
|
[1] |
BEARING-T/R
|
|
| 5. |
XKCF-00516
|
[AR] |
SHIM (0.1)
|
|
| 5. |
XKCF-00517
|
[AR] |
SHIM (0.15)
|
|
| 5. |
XKCF-00518
|
[AR] |
SHIM (0.25)
|
|
| 5. |
XKCF-00519
|
[AR] |
SHIM (0.5)
|
|
| 6. |
XKCF-00520
|
[1] |
SPACER
|
|
| 7. |
XKCF-00521
|
[AR] |
SHIM (0.1)
|
|
| 7. |
XKCF-00607
|
[AR] |
SHIM (0.12)
|
|
| 7. |
XKCF-00522
|
[AR] |
SHIM (0.15)
|
|
| 7. |
XKCF-00523
|
[AR] |
SHIM (0.2)
|
|
| 8. |
XKCF-00524
|
[1] |
BEARING-T/R
|
|
| 9. |
XKCF-00525
|
[10] |
BOLT-HEX
|
|
| 10. |
XKCF-00526
|
[4] |
PIN-PALARELL
|
|
| 11. |
XKCF-00527
|
[4] |
PLATE-PARKING
|
|
| 12. |
XKCF-00528
|
[3] |
PLATE-FRICTION
|
|
| 13. |
XKCF-00529
|
[12] |
SPRING-CON
|
|
| 14. |
XKCF-00530
|
[1] |
ACTUATOR
|
|
| 15. |
XKCF-00531
|
[1] |
SPLINE-PARKING
|
|
| 16. |
XKCF-00532
|
[2] |
LOCK PIN
|
|
| 17. |
XKCF-00330
|
[2] |
DOWEL PIN
|
|
| 18. |
XKCF-00533
|
[1] |
COVER-CARRIER CASE
|
|
| 19. |
XKCF-00614
|
[1] |
OIL SEAL
|
|
| 20. |
XKCF-00535
|
[1] |
SCREW-SET
|
|
| 21. |
XKCF-00608
|
[1] |
O-RING
|
|
| 22. |
XKCF-00537
|
[1] |
COLLOR
|
|
| 23. |
XKCF-00538
|
[1] |
LEVER
|
|
| 24. |
XKCF-00539
|
[1] |
LEVER
|
|
| 25. |
XKCF-00904
|
[1] |
O-RING
|
|
| 26. |
S601-016004
|
[1] |
RING-RETAINING
|
|
| 27. |
XKCF-00541
|
[1] |
CAP-C/CASE COVER
|
|
| 28. |
S017-080502
|
[8] |
BOLT-HEX
|
|
| 29. |
XKCF-00542
|
[1] |
FLANGE U-JOINT
|
|
| 30. |
XKCF-00615
|
[1] |
O-RING
|
|
| 31. |
XKCF-00543
|
[1] |
NUT-T/P BEARING
|
|
| 32. |
S471-500324
|
[2] |
PIN-SPRING
|
|
