现代零件查询20L/25L/30L-7 DRIVE AXLE ASSY(NEW)EPC Hyundai _现代Hyundai_工程机械

现代零件查询20L/25L/30L-7 DRIVE AXLE ASSY(NEW)EPC Hyundai

广数供应链运营团队, 16 02月, 2025，浏览： 539 次

Pos.	Part No	Qty	Parts name	Comments
.	81HA-31020	[1]	DRIVE AXLE ASSY	20L-7
.	81HA-31021	[1]	DRIVE AXLE ASSY	20L-7
.	81HA-31020	[1]	DRIVE AXLE ASSY	25L-7
.	81HA-31021	[1]	DRIVE AXLE ASSY	25L-7
.	81HA-31020	[1]	DRIVE AXLE ASSY	30L-7
.	81HA-31021	[1]	DRIVE AXLE ASSY	30L-7
1.	XKCF-00579	[1]	HOUSING-AXLE
2.	XKCF-00580	[1]	CARRIER SUB ASSY
3.	XKCF-00299	[6]	PIN-PARALLEL
4.	XKCF-00581	[9]	BOLT-HEX
5.	XKCF-00582	[1]	AXLE SHAFT-LH
6.	XKCF-00583	[1]	AXLE SHAFT-RH
7.	S601-030004	[4]	RETAINING RING
8.	XKCF-00478	[2]	BEARING-BALL
9.	S602-055004	[2]	RING-RETAINING,C TYPE
10.	XKCF-00586	[2]	PISTON	20L-7
10.	XKCF-01098	[2]	PISTON	20L-7
10.	XKCF-00586	[2]	PISTON	25L-7
10.	XKCF-01098	[2]	PISTON	25L-7
10.	XKCF-00586	[2]	PISTON	30L-7
10.	XKCF-01098	[2]	PISTON	30L-7
11.	XKCF-01100	[8]	SLEEVE
12.	XKCF-00587	[2]	RING-SQUARE	20L-7
12.	XKCF-00659	[2]	RING(S)-QUAD	20L-7
12.	XKCF-00587	[2]	RING-SQUARE	25L-7
12.	XKCF-00659	[2]	RING(S)-QUAD	25L-7
12.	XKCF-00587	[2]	RING-SQUARE	30L-7
12.	XKCF-00659	[2]	RING(S)-QUAD	30L-7
13.	XKCF-00588	[2]	RING-SQUARE	20L-7
13.	XKCF-00658	[2]	RING(B)-QUAD	20L-7
13.	XKCF-00588	[2]	RING-SQUARE	25L-7
13.	XKCF-00658	[2]	RING(B)-QUAD	25L-7
13.	XKCF-00588	[2]	RING-SQUARE	30L-7
13.	XKCF-00658	[2]	RING(B)-QUAD	30L-7
14.	XKCF-01103	[8]	BOLT-SPECIAL
15.	XKCF-01101	[8]	SPRING
16.	XKCF-00589	[8]	PIN-PARALLEL
17.	XKCF-00590	[10]	PLATE
19.	XKCF-00591	[8]	FRICTION PLATE
20.	XKCF-00592	[2]	HOUSING-CARRIER
21.	XKCF-00261	[2]	TAPER ROLLER BEARING
22.	XKCF-00302	[AR]	SHIM (0.1T)
22.	XKCF-00303	[AR]	SHIM (0.15T)
22.	XKCF-00304	[AR]	SHIM (0.25T)
22.	XKCF-00305	[AR]	SHIM (0.5T)
22.	XKCF-00890	[AR]	SHIM (0.12T)	20L-7
22.	XKCF-00890	[AR]	SHIM (0.12T)	25L-7
22.	XKCF-00890	[AR]	SHIM (0.12T)	30L-7
23.	XKCF-00593	[2]	SPACER
24.	XKCF-00318	[2]	TAPER ROLLER BEARING
25.	XKCF-00594	[2]	HUB-FLANGE
26.	XKCF-00595	[2]	WHEEL SHAFT
27.	XKCF-00613	[20]	BOLT-HEX
28.	XKCF-00597	[2]	SEAL-OIL
29.	XKCF-00598	[10]	BOLT-HUB
30.	XKCF-00599	[2]	CARRIER-PLANETARY	20L-7
30.	XKCF-00891	[2]	CARRIER-PLANETARY	20L-7
30.	XKCF-00599	[2]	CARRIER-PLANETARY	25L-7
30.	XKCF-00891	[2]	CARRIER-PLANETARY	25L-7
30.	XKCF-00599	[2]	CARRIER-PLANETARY	30L-7
30.	XKCF-00891	[2]	CARRIER-PLANETARY	30L-7
31.	XKCF-00268	[2]	LOCKNUT	20L-7
31.	XKCF-00892	[2]	NUT-LOCK	20L-7
31.	XKCF-00268	[2]	LOCKNUT	25L-7
31.	XKCF-00892	[2]	NUT-LOCK	25L-7
31.	XKCF-00268	[2]	LOCKNUT	30L-7
31.	XKCF-00892	[2]	NUT-LOCK	30L-7
32.	XKCF-00600	[12]	THRUST WASHER	20L-7
32.	XKCF-00600	[6]	THRUST WASHER	20L-7
32.	XKCF-00600	[12]	THRUST WASHER	25L-7
32.	XKCF-00600	[6]	THRUST WASHER	25L-7
32.	XKCF-00600	[12]	THRUST WASHER	30L-7
32.	XKCF-00600	[6]	THRUST WASHER	30L-7
33.	XKCF-00601	[114]	ROLLER-NEEDLE
34.	XKCF-00602	[6]	GEAR-PLANETARY
35.	XKCF-00603	[6]	RING-RETAINING
36.	XKCF-00616	[2]	SEAL-OIL
37.	XKCF-00604	[2]	O-RING
38.	XKCF-00007	[2]	PLUG-HEX
39.	XKCF-00501	[24]	BOLT-SOCKET
40.	XKCF-00266	[2]	FITTING-BLEEDER
41.	XKCF-00314	[2]	O-RING
42.	XKCF-00288	[2]	VALVE-BLEEDING
43.	XKCF-00289	[2]	BLEEDER CAP
44.	XKCF-00502	[1]	BREATHER-AIR
45.	XKCF-00503	[1]	GAUGE-DIP STICK
46.	XKCF-00153	[1]	PLUG-MAGNET
47.	XKCF-00260	[2]	PLUG-MAGNETIC
48.	XKCF-00504	[1]	BRACKET
49.	XKCF-00605	[2]	BOLT-HEX
50.	XKCF-00158	[12]	NUT-HUB
51.	XKCF-00893	[6]	THRUST WASHER	20L-7
51.	XKCF-00893	[6]	THRUST WASHER	25L-7
51.	XKCF-00893	[6]	THRUST WASHER	30L-7
52.	XKCF-00894	[2]	SET SCREW	20L-7
52.	XKCF-00894	[2]	SET SCREW	25L-7
52.	XKCF-00894	[2]	SET SCREW	30L-7
53.	XKCF-00235	[20]	WASHER-SPRING	20L-7
53.	XKCF-00235	[20]	WASHER-SPRING	25L-7
53.	XKCF-00235	[20]	WASHER-SPRING	30L-7
54.	XKCF-00661	[2]	RING(S)-BACKUP	20L-7
54.	XKCF-00661	[2]	RING(S)-BACKUP	25L-7
54.	XKCF-00661	[2]	RING(S)-BACKUP	30L-7
55.	XKCF-00660	[2]	RING(B)-BACKUP	20L-7
55.	XKCF-00660	[2]	RING(B)-BACKUP	25L-7
55.	XKCF-00660	[2]	RING(B)-BACKUP	30L-7
-1.	XKCF-00874	[2]	HUB ASSY	SEE ILLUST
-2.	XKCF-00656	[2]	PISTON SUB ASSY	SEE ILLUST
-3.	XKCF-01097	[2]	AUTO-ADJUST KIT	20L,USE A/S
-3.	XKCF-01097	[2]	AUTO-ADJUST KIT	25L,USE A/S
-3.	XKCF-01097	[2]	AUTO-ADJUST KIT	30L,USE A/S
