Pos.	Part No	Qty	Parts name	Comments
1.	25H522	[1]	Groove Pin	3/16" X 7/8"
2.	R39152	[1]	Pin Fastener
3.	AR39040	[1]	Arm
4.	25H522	[2]	Groove Pin	3/16" X 7/8"
5.	19H3483	[1]	Cap Screw	3/8" X 1-1/8"
6.	12H304	[1]	Lock Washer	3/8"
7.	R98923	[1]	Gasket	(SUB FOR R39163)
8.	R39248	[1]	Strap
9.	R39162	[1]	Plate
10.	R98922	[1]	Gasket	(SUB FOR R39161)
11.	24H1286	[5]	Washer	9/32" X 1/2" X 1/16"
12.	19H2935	[5]	Screw	1/4" X 1-1/2"
13.	R27218	[1]	Fitting Plug
14.	R26448	[1]	O-Ring
15.	........	[1]	Valve Cover	(WHEN AR39138 IS NO LONGER AVAILABLE SUB R39160, R26448 AND R27218)
15.	R39160	[1]	Valve Cover	(DOES NOT INCLUDE PLUG AND O-RING)
16.	R33521	[6]	Shim
16.	B1085R	[AR]	Washer
16.	T33473	[AR]	Shim
17.	R39132	[1]	Spring
18.	R39294	[1]	Pin Fastener
19.	AR39064	[1]	Shaft
20.	R83001	[1]	Arm	INNER, (SUB FOR T39521)
21.	19H1912	[1]	Cap Screw	3/8" X 3-1/2"
22.	24M7096	[3]	Washer	0.413" X 0.709" X 0.063"
23.	19H3267	[2]	Cap Screw	3/8" X 1-5/8"
