约翰迪尔零件查询300B - BACKHOE, LOADER REVERSER CLUTCH CONTROL VALVE AND PISTON [01F06]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 228 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2932	[6]	Screw	1/4" X 1"
2.	12H303	[6]	Lock Washer	5/16"
3.	R72874	[1]	Gasket	(SUB FOR R39159)
4.	T39520	[1]	Valve
5.	F3366R	[1]	Snap Ring
6.	R72654	[1]	Snap Ring	(SUB FOR R27507)
7.	R31319	[1]	Pin
8.	R39137	[1]	Spring
9.	R39140	[1]	Pin Fastener
10.	R26287	[2]	O-Ring
11.	R27216	[2]	Drain Plug	(SUB FOR R31631)
12.	AR39043	[2]	Seal
13.	D2361R	[1]	Ball
14.	R33277	[1]	Spring
14.	T31636	[1]	Spring
15.	R26906	[1]	O-Ring
16.	R39164	[1]	Plug
16.	T73891	[1]	Fitting
17.	R54579	[1]	Housing
18.	R39294	[1]	Pin Fastener
19.	F3322R	[1]	Spring
20.	R39133	[1]	Spring
21.	R39229	[1]	Spring
22.	34H310	[1]	Spring Pin	1/4" X 3/4"
23.	R39149	[1]	Valve	PRESSURE, CLUTCH
24.	R34028	[1]	Bolt
25.	R87627	[1]	O-Ring	(SUB FOR R27976, THIS APPLICATION)
26.	R63364	[1]	Piston	(SUB FOR R39131)
27.	R27216	[1]	Drain Plug	(SUB FOR R31631)
28.	R26287	[1]	O-Ring
29.	R39158	[1]	Cover
30.	T113380	[1]	Pressure Relief Valve	COOLER RELIEF, (SUB FOR R39294 AND T59404)
