约翰迪尔零件查询300B - BACKHOE, LOADER SELECTIVE CONTROL VALVE LEVERS AND ARMS [01H12]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 490 次

Pos.	Part No	Qty	Parts name	Comments
1A.	R39289	[1]	Cover
1B.	R69880	[1]	Cover
2.	R26149	[1]	Packing
3.	R26149	[2]	Packing
4.	19H1895	[1]	Cap Screw	(D) 1/2" X 3/4"
5.	24H1625	[1]	Washer	(D) 17/32" X 1" X 0.120"
6.	T23069	[1]	Lever	(D) INNER
7A.	T22883	[1]	Grip
7B.	R62147	[1]	Grip	(D)
8A.	T22883	[1]	Grip
8B.	R62148	[1]	Grip
9.	T23071	[1]	Lever	OUTER (DUAL)
10.	AR39158	[1]	Arm	OUTER (DUAL)
11.	AR39157	[1]	Arm	INNER
12.	R394R	[2]	O-Ring
12.	R65287	[2]	O-Ring
13.	R26375	[2]	O-Ring	(D)
14.	R39112	[2]	Fitting
15.	R26375	[3]	O-Ring
16.	R41155	[1]	Fitting Plug	3/4"
17.	AR26697	[1]	Sealing Washer
18.	R27218	[1]	Fitting Plug	9/16"
19.	R26448	[1]	O-Ring
20.	19H1912	[3]	Cap Screw	3/8" X 3-1/2", (SINGLE)
20.	19H3328	[3]	Cap Screw	3/8" X 6-1/2", (DUAL)
21.	R27237	[2]	Fitting	(D)
22.	14H812	[1]	Nut	3/8"
23.	AR40828	[1]	Housing	(MARKED R40599) (SUB AR83549, AR85628 AND R65289)
23.	AR83549	[1]	Housing	(MARKED R65504)
...	AR91861	[1]	Valve	POPPET DOUBLE ACTING, SINGLE WITH LEVER LOCK, FOR USE WITH 5.00 TO 1 FINAL DRIVE RATIO, (SUB FOR AR76093) (INCLUDES (2) AR21837, AR91029, AR99025, AT35120, (2) R26906, (2) R39171, R77420, R20922, T22996, (2) 14H732 AND (2) 19H3597)
