约翰迪尔零件查询300B - BACKHOE, LOADER RIGHT AND LEFT LIFT LINKS (CATEGORY I AND II) [01J10]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
694 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T21901
|
[2] |
Ball
|
|
| 2. |
11M7030
|
[2] |
Cotter Pin
|
|
| 3. |
AT21754
|
[2] |
Pin Fastener
|
|
| 4. |
T25836
|
[1] |
Link End
|
|
| 4. |
T24909
|
[1] |
Spacer
|
|
| 5. |
R48595
|
[2] |
Link Body
|
|
| 6. |
T162396
|
[3] |
Lubrication Fitting
|
|
| 7. |
AR68071
|
[1] |
Tie-Down Strap
|
|
| 8. |
T25835
|
[1] |
Shaft
|
|
| 8. |
T24908
|
[1] |
Shaft
|
|
| 9. |
T22399
|
[1] |
Ball
|
|
| 10. |
T21462
|
[1] |
Housing
|
|
| 10. |
L28374
|
[1] |
Housing
|
|
| 11. |
P46051
|
[1] |
O-Ring
|
|
| 12. |
34H314
|
[1] |
Spring Pin
|
|
| 13. |
T21559
|
[1] |
Handle
|
|
| 14. |
T21558
|
[1] |
Shaft
|
|
| 15. |
JD9812
|
[2] |
Thrust Bearing Race
|
|
| 16. |
JD8856
|
[1] |
Needle Bearing
|
|
| 17. |
T21903
|
[1] |
Washer
|
|
| 18. |
T21758
|
[1] |
Adapter Fitting
|
|
| 19. |
T32488
|
[1] |
Washer
|
|
