约翰迪尔零件查询300B - BACKHOE, LOADER SEAT SUPPORT SLIDES (WITH BACKHOE) (SERIAL NO. -308459) [02B09]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
390 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T30456
|
[1] |
Pan
|
|
| 2. |
AT29240
|
[1] |
Plate
|
|
| 3. |
12H304
|
[3] |
Lock Washer
|
|
| 4. |
19H3065
|
[1] |
Cap Screw
|
|
| 5. |
T39497
|
[1] |
Spring
|
|
| 6. |
AT29245
|
[1] |
Plate
|
|
| 7. |
12H303
|
[8] |
Lock Washer
|
|
| 8. |
14H650
|
[4] |
Nut
|
|
| 9. |
14H786
|
[2] |
Nut
|
|
| 10. |
12H302
|
[2] |
Lock Washer
|
|
| 11. |
T30467
|
[1] |
Support
|
|
| 12. |
T30468
|
[1] |
Pin
|
|
| 13. |
R26169
|
[1] |
Spring
|
|
| 14. |
........
|
[1] |
Spring Pin
|
|
| 15. |
T30469
|
[1] |
Bushing
|
|
| 16. |
19H2036
|
[2] |
Cap Screw
|
|
| 17. |
R31291
|
[1] |
Snap Ring
|
|
| 18. |
AT37474
|
[1] |
Adjuster
|
|
| 19. |
AT36733
|
[1] |
Adjuster
|
|
| 20. |
24H1621
|
[4] |
Washer
|
|
| 21. |
19H3239
|
[2] |
Cap Screw
|
|
| 22. |
14H882
|
[4] |
Nut
|
|
| 23. |
21H1128
|
[2] |
Screw
|
|
| 24. |
T39140
|
[1] |
Handle
|
|
| 25. |
T531T
|
[2] |
Lock Nut
|
|
| 26. |
T38065
|
[6] |
Screw
|
|
| 27. |
24H1308
|
[12] |
Washer
|
|
