| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AT29248 | [1] | Bracket | |
| 2. | 12H301 | [4] | Lock Washer | 1/2" |
| 3. | 19H2898 | [4] | Cap Screw | 1/2" X 1-1/4" |
| 4. | T30486 | [1] | Pivot | |
| 5. | ........ | [4] | Bushing | ( T30484 NO LONGER AVAILABLE) |
| 6. | 19H1550 | [3] | Cap Screw | 5/8" X 5" |
| 7. | 12H294 | [3] | Lock Washer | 5/8" |
| 8. | 11M7081 | [2] | Cotter Pin | 2.500 X 20 MM |
| 9. | 24H1305 | [2] | Washer | 13/32" X 13/16" X 0.065" |
| 10. | T30485 | [1] | Pin Fastener |
